Product Center

Medium voltage MOS

SOT23

Medium voltage MOS

　　 The medium voltage MOSFET is manufactured using FZWELEC micro trench and planar process technology. The advanced technology and cell structure make the product realize the maximum power density, thereby greatly reducing the conduction loss during the current conduction process, and has low conduction resistance, superior switching performance and high avalanche breakdown tolerance. .

　　1, lower gate charge,

　　2, lower reverse transmission capacitance

　　3, faster switching speed

　　4, higher dv/dt capability

Part_Number
Package
Configuration
Type
ESD_Diode
Vds(V)
Vgs(+V)
Vth(V)
Rds(on)mΩmax2.5V
Rds(on)mΩ max4.5V
Rds(on)mΩ max10V
ID(A)

~ V
~ V
~ V
~ V
~ V
~ V
~ V

Part_Number	Package	Configuration	Type	ESD_Diode	Vds(V)	Vgs(±V)	Vth(V)	Rds(on)mΩ max2.5V	Rds(on)mΩ max4.5V	Rds(on)mΩ max10V	ID(A)
FB1210	SOT23	Single	N	No	20	20	2	0	10	9	12
FB1240	SOT23	Single	N	No	20	8	0	33	24	0	6
FB1240B	SOT23	Single	N	No	20	20	1	25	20	0	6
FB1307N	SOT23	Single	N	No	30	20	1	0	62	47	5
FB1330	SOT23	Single	N	No	30	20	1	0	33	30	7
FB1435	SOT23	Single	N	No	40	20	1	0	40	35	5
FBB2355	SOT23-3L	Single	P	No	-30	20	-1	0	75	60	-5
FB162K	SOT23	Single	N	No	60	20	2	0	3000	2800	0
FB1695	SOT23	Single	N	No	60	20	1	0	96	85	4
FB1101M	SOT23	Single	N	No	100	20	1	0	150	120	4
FB1102M	SOT23	Single	N	No	100	20	2	0	260	246	2
FB1106K	SOT23	Single	N	No	100	20	1	0	3000	2800	0
FB1201K	SOT23	Single	N	No	200	20	1	0	1440	1200	1
FB165R01	SOT23	Single	N	No	650	30	1	0	0	8400	1
FB2212N	SOT23	Single	P	No	-20	12	-1	120	88	71	-4
FB2290	SOT23	Single	P	No	-20	12	-1	83	57	0	-4
VB2240	SOT23	Single	P	No	-20	12	-1	38	32	29	-5
FB2290A	SOT23	Single	P	No	-20	20	-1	89	60	47	-4
FB2355	SOT23	Single	P	No	-30	20	-1	0	56	47	-6
FB2470	SOT23	Single	P	No	-40	20	-2	0	110	83	-4
FB2610N	SOT23	Single	P	No	-60	20	-2	85	70	0	-5
FB264K	SOT23	Single	P	No	-60	20	-2	0	3680	3000	-1
FB2658	SOT23	Single	P	No	-60	20	-2	0	48	40	-5
FB2101K	SOT23	Single	P	No	-100	20	-3	0	56	50	-2
FB2103K	SOT23	Single	P	No	-100	20	-3	0	3600	3000	0
FB2201K	SOT23	Single	P	No	-200	20	-2	0	1100	1000	-1
FBB1328	SOT23-3L	Single	N	No	30	20	1	0	22	16	7
FBB1630	SOT23-3L	Single	N	No	60	20	1	0	36	30	6
